pipe prefabrication automatic welding machine pipe prefabrication automatic welding machine is specially designed and manufactured for the purpose of meeting the requirements of enhancing productivity, increasing the extent of automatic, reducing welder's working intensity and adapting to piping workshop prefabrication.

The welding head will be relatively fixed, while the piping spool piece revolving at a specific rate, and the high efficient and low cost shielded welding or SAW process is adopted, so it has the features of easy-operation, reliable-performance and wide-application field.

pipe diameter applicable φ50~φ426mm welding speed 70~1700mm/min welding process MIG , MAG , SAW seams pipe + pipe , pipe + piece , piece + piece Automatic girth seam machine TIG , MIG/MAG , PLASMA ,,,,,,,,.

Applicable for the welding of various cylinder workpiece by TIG, MIG, MAG and PLASMA , its structure including horizontal, stand and adjustable principal axis, and assembling with headstock, lathe bed, bracket ,control system etc.

For all arc welding processes, it is important that the welding head be rigidly mounted over the part to be welded to obtain the highest quality weld results. Any vibration or instability of the weld head mounting will have an effect upon the arc length and produce inferior results.

Welding manipulator is used when the weld head has to be moved to a position relative to the work piece. Welding manipulator provide the perfect solution as the boom can be lifted and lowered on the column and can be extended or retracted as required, The ends of boom are machined to carry a welding head.

This machine and welder composed of auto welding mechanical equipment. It can use with welding rotator, widely applied to industries such as boiler, pressure vessel, petroleum, chemical industry and mechanism. + Structure : stationary, stationary and revolve , moving and revolve type.

+ Cross section of boom and column are rectangular-section beams, with double-rail, welded into shape , stress-relieved and mechanical machined finely, ensuring higher precision;+ Drooping of boom along horizontal travel is 2mm/m.

+ Boom lifting device including ratchet-type anti-dripping unit on the column, safe and reliable to prevent chains from incidental broken. + Guide roller is eccentric structure, decrease clearance between roller and rail surface, ensuring smooth and no shiv
